【Scope of Application】

It is suitable for the different requirements of the textile and apparel, petrochemical, labor safety protection, and quality supervision and inspection industries and institutions for the liquid tightness test of protective clothing. It is used for the development of chemical protective clothing, quality control in the production process, and the use of chemical protective clothing. The detection of confidentiality provides a scientific and reliable basis.

【standard test】

It is suitable for the test method requirements of the national standard GB 24540-2009 "Protective clothing, acid-base chemical protective clothing", and can be used to determine the splash liquid tightness and spray liquid tightness of chemical protective clothing.

【Main Specifications】

1. Time setting range: 0～99.99s; resolution: 0.01s;

2. Turntable speed: 1 r/min;

3. The installation distance of nozzles on the spray rod: 450mm;

4. The distance between the center of the spray rod and the center of the turntable: 1500mm;

5. Nozzle spray angle: 75°;

6. Liquid supply pressure: 300 Kpa (splash test);

7. Splashing flow rate: 1.14±0.1 L/min;

8. Jet nozzle: nozzle diameter (4±1) mm, nozzle length (4±1) mm, nozzle tube inner diameter (12.5±1) mm;

9. The distance between the jet pressure gauge and the nozzle opening is (80±1) mm;

10. The liquid pressure at the jet pressure gauge is 150kPa;

11. Power supply: AC220V±10% /50Hz Total power: ≤1.65KW

12. Appearance size: 2000mm×1000mm×2940mm (test room)

800mm×600mm×750mm (host controller)

13. Weight: 800KG
