【Scope of application】

It is used to test the mechanical properties of various textiles such as stretching, tearing, bursting, constant elongation, constant load, elasticity, suture slippage, peeling, etc., and is widely used in rubber, plastic, leather, metal, wire, paper , Packaging, building materials, petrochemical, electrical, geotechnical materials, tensile, compression, bending, bonding, peeling, tearing, bursting, creep and other tests of force, elongation, deformation test.

【Related standards】

GB/T3923.1/2 GB/T13772.1/2/3 GB8687 FZ/T20019 FZ/T70006 FZ/T01085 FZ/T01030 FZ/T70007 ISO13934.1/2 ISO13935.1/2 ISO4606 ISO9073.3/4 ASTM D5034 ASTM D5035 ASTM D2261 ASTM D434 ASTM D4964 ASTM D5587 ASTM D3936 JIS L1093 BS DIN etc.

【technical parameter】

1,  Test method: measured according to the national preferred constant velocity elongation (CRE) test principle, the whole process is controlled by a high-speed processor, And record the changes every moment (curve dynamic monitoring), and breaking strength, breaking elongation (elongation), time, number of times, etc.

2,  Force measuring system: Imported high-precision force sensor is adopted.

3,  Test method: single yarn, fabric stretch, burst, peel, tongue tear, trapezoidal tear, fixed stretch Length, constant load, underarm seams, suture slip (optional)

4,  Range: 500N / 1000 N / 2500N / 5000N (optional)

5,  Force measurement accuracy: ≤±0.02%F.S

6,  Clamping distance adjustment accuracy: ±0.1mm

7,  Stretching speed: 0-1000mm/min digital speed regulation, error ≤±2% (arbitrarily set)

8、Gantry width: 410mm

9,  Effective stroke: 1000mm

10, Elongation resolution: 0.001mm

11,  Sampling frequency: 2500 times/sec

12,  Fixture: pneumatic or manual

13, Maximum cumulative test times (maximum data capacity of continuous test): 5000 times (can be grouped arbitrarily)

14, Print: output print results in various forms

15,  Power supply: AC220V±10％50Hz

16, Dimensions: 800×510×1650mm (L×W×H)

17,  Weight: about 160 Kg
