【Scope of application】

It is used to test the mechanical properties of various textiles such as stretching, tearing, bursting, constant elongation, constant load, elasticity, suture slippage, peeling, etc., and is widely used in rubber, plastic, leather, metal, wire, paper , Packaging, building materials, petrochemical, electrical, geotechnical materials, tensile, compression, bending, bonding, peeling, tearing, bursting, creep and other tests of force, elongation, deformation test.

【Related standards】

GB/T3923.1, ISO13934.1, ISO13935.1, ISO9073.3/4, ASTM D5035, ASTM D2261, etc.

【technical parameter】

1. Structure: CRE constant velocity stretching

2. Measuring force range: 1000N, 2000N, 3000N (optional range)

3. Effective test stroke: 1000mm (without fixture)

4. Load measurement range: 0-100% of the maximum load

5. Load measurement accuracy: +0.02% F·S

6. Stretching speed: 0—300mm/min stepless speed regulation

7. Speed accuracy: ±2%

8. Fixture configuration: a set of pneumatic tensile fixtures (other functional fixtures can be customized according to user test requirements)

9. Result output: built-in thermal printer, test results can be printed, and online operation (optional)

10. Dimensions: 500×400×1400(mm)

11. Power supply: single-phase AC 220V±10%V

12. Weight: 90kg
